250ml - 2000ml Bottle Filling Line

Chiny 250ml - 2000ml Bottle Filling Line  dostawca
250ml - 2000ml Bottle Filling Line  dostawca 250ml - 2000ml Bottle Filling Line  dostawca 250ml - 2000ml Bottle Filling Line  dostawca 250ml - 2000ml Bottle Filling Line  dostawca

Duży Obraz :  250ml - 2000ml Bottle Filling Line

Szczegóły Produktu:

Place of Origin: China Mainland
Nazwa handlowa: Jiayuan
Orzecznictwo: CE,SGS
Model Number: RCGF18-18-18-6

Zapłata:

Minimum Order Quantity: 1 set
Cena: Negotiation
Packaging Details: Seaworthy Wooden Case
Delivery Time: 40 days
Payment Terms: T/T; L/C
Supply Ability: 3 sets/month
Verified Supplier

China Mainland

  • Product Details
Szczegółowy opis produktu
Application: Juice Automatic Grade: Automatic
Bottle type: PET, 250ml - 2000ml Capacity: 6000BPH
Feature: Aseptic Product name: Hot Filling Machine
High Light:

Liquid Filling Machine

,

Bottle Filling Equipment





250ml - 2000ml Bottle Filling Line Fully Automatic For Beverage





Quick Detail:



  1. 6000bph juice filling plant
  2. Production capacity: 4000-20000bph
  3. Bottle size: 250-2000ml
  4. Rinsing, washing, filling, capping machine 4-1
  5. Material: SS304
  6. Warranty: 1year free





Description:



Main features:

6000bph juice filling plant main features:

1. All parts, for instance, filling valve, which directly contact medium are made of stainless steel. So it conforms to the requirements of food sanitation.

2. Sealing parts are made of heat-proofing rubber, in order to meet the technique requirements of users to sterilize the whole machine at high temperature.

3. 4 in1 Juice filling machine Using programmable controller to realize fully automatic control from bottles entering to finishing packing.

4. 4in1 Juice filling machine Using advanced magnetic coupler to regulate cap-screwing torque, in order to assure capping quality.





Application:


This Juice filling machine adopts German technology, combined with years of experience in the Company after the development of new products. RXG series hot juice filling machine is the standard 3-in-1 monoblock. But to the special production condition, another sanitizer rinsing could be added, that is 4-in-1 monoblock. The system has fully considered the beverage’s characteristics (such as the frothing of the tea drink and mixed juice) and the technical requirement of the hot filling.4 in 1 Washing, Filling (Pulp), Filling (juice), capping machine. Or Washing (disinfectant), Washing (pure water), Filling, Capping machine. Custom machines according to different requirements for the user.





Specifications:



6000bph juice filling plant

Model:

RCGF18-18-18-6

RCGF24-24-24-8

RCGF32-32-32-10

RCGF40-40-40-12

capacity :500ml

6000

bottle per hour

10000

bottle per hour

15000

 bottle per hour

20000

bottle per hour

bottle shape:

round or square

PET bottle: (mm)

(Bottle Diameter):φ50-.φ110mm

(Height):150-340mm

cap:

PE screw cap

filling precision:

≤±5mm

filling pressure:(Mpa)

0.15-0.35

0.15-0.35

0.15-0.35

0.15-0.35

rinsing pressure:(Mpa)

0.2-0.25

0.2-0.25

0.2-0.25

0.2-0.25

filling volume :(L)

3.5

4

6

8

overall size:(mm)

2450*1800
*2350

2780*2200
*2350

3600*2650
*2350

3800*2950
*2400

weight: (kg)

3500

4500

5500

6500

250ml - 2000ml Bottle Filling Line  0

250ml - 2000ml Bottle Filling Line  1250ml - 2000ml Bottle Filling Line  2250ml - 2000ml Bottle Filling Line  3
